NDXD4805EC
ActiveMurata Power Solutions Inc.
DC DC CONVERTER +/-5V 7W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NDXD4805EC
ActiveMurata Power Solutions Inc.
DC DC CONVERTER +/-5V 7W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | NDXD4805EC | NDXD48 Series |
|---|---|---|
| Applications | ITE (Commercial) | ITE (Commercial) |
| Current - Output (Max) | 750 mA | 250 - 750 mA |
| Current - Output (Max) | 750 mA | 250 - 750 mA |
| Efficiency | 77 % | 77 % |
| Mounting Type | Through Hole | Through Hole |
| Number of Outputs | 2 | 2 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 6-DIP Module | 6-DIP Module |
| Power (Watts) | 7 W | 7 W |
| Type | Isolated Module | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V | 75 V |
| Voltage - Input (Min) [Min] | 36 V | 36 V |
| Voltage - Isolation | 1000 V | 1000 V |
| Voltage - Output 1 | 5 V | 5 - 15 V |
| Voltage - Output 2 | -5 V | -15 - -5 V |
NDXD48 Series
DC DC CONVERTER +/-12V 7W
| Part | Current - Output (Max) | Current - Output (Max) | Number of Outputs | Voltage - Isolation | Voltage - Output 1 | Voltage - Input (Max) [Max] | Mounting Type | Type | Applications | Power (Watts) | Voltage - Input (Min) [Min] | Voltage - Output 2 | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. NDXD4812EC | 312 mA | 312 mA | 2 | 1000 V | 12 V | 75 V | Through Hole | Isolated Module | ITE (Commercial) | 7 W | 36 V | -12 V | 6-DIP Module | 85 °C | -40 °C | |
Murata Power Solutions Inc. NDXD4815C | 250 mA | 250 mA | 2 | 1000 V | 15 V | 75 V | Through Hole | Isolated Module | ITE (Commercial) | 7 W | 36 V | -15 V | 6-DIP Module | 85 °C | -40 °C | |
Murata Power Solutions Inc. NDXD4805EC | 750 mA | 750 mA | 2 | 1000 V | 5 V | 75 V | Through Hole | Isolated Module | ITE (Commercial) | 7 W | 36 V | -5 V | 6-DIP Module | 85 °C | -40 °C | 77 % |
Murata Power Solutions Inc. NDXD4805C | 750 mA | 750 mA | 2 | 1000 V | 5 V | 75 V | Through Hole | Isolated Module | ITE (Commercial) | 7 W | 36 V | -5 V | 6-DIP Module | 85 °C | -40 °C | 77 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
NDXD48 Series
Isolated Module DC DC Converter 2 Output 5V -5V 750mA, 750mA 36V - 75V Input
