MAL213249221E3
ActiveVishay Dale
CAP ALUM 220UF 100V SNAP TH
MAL213249221E3
ActiveVishay Dale
CAP ALUM 220UF 100V SNAP TH
Description
General part information
MAL213249221E3
220 µF 100 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 3 Lead 430mOhm @ 100Hz 15000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL213249221E3 |
|---|---|
| Applications | General Purpose |
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 430 mOhm |
| Height - Seated (Max) | 1.654 in |
| Lifetime | 15000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 3 Leads |
| Package Name | Radial, Can - Snap-In |
| Polarization | Polar |
| Ripple Current | 660 mA |
| Size / Dimension Diameter | 0.709 in |
| Tolerance (Negative) | 10 % |
| Tolerance (Positive) | 50 % |
| Voltage - Rated | 100 VAC/DC |
