WIREFC-501332-0454
ActiveIndium Corporation of America
SN99.3 CU0.7 CW818 3% 0.062" 1LB
WIREFC-501332-0454
ActiveIndium Corporation of America
SN99.3 CU0.7 CW818 3% 0.062" 1LB
Description
General part information
WIREFC-501332-0454
SN99.3 CU0.7 CW818 3% 0.062" 1LB
Technical Specifications
Parameters and characteristics for this part
| Specification | WIREFC-501332-0454 |
|---|---|
| Composition Elements | Sn, Cu |
| Composition Formula | Sn99.3Cu0.7 |
| Cu Composition | 0.7 % |
| Diameter | 0.062 in |
| Form | Spool |
| Form Weight | 1 lb |
| Melting Point | 441 °F |
| Process | Lead Free |
| Shelf Life | 120 Months |
| Shelf Life Start | Date of Manufacture |
| Sn Composition | 99.3 % |
| Storage/Refrigeration Temperature (Maximum) | 104 °F |
| Storage/Refrigeration Temperature (Minimum) | 50 °F |
| Type | Wire Solder |
| Wire Gauge | 16 SWG, 14 AWG |
