Specification	D38999/26FG41PB

Applications	Aerospace, Aviation, Military, Marine
Color	Silver
Connector Type	Male Pins, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	50 µin
Contact Material	Copper Alloy
Current Rating	7.5 A
Fastening Type	Threaded
Features	Coupling Nut, Self Locking
Grade	Military
Ingress Protection	Weathertight
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	41
Operating Temperature (Max)	200 °C
Operating Temperature (Min)	-65 °C
Orientation	B
Primary Material	Metal
Qualification	MIL-DTL-38999 Series III
Shell Finish	Nickel, Electroless Nickel
Shell Material	Aluminum
Shell Size - Insert (Maximum)	41
Shell Size - Insert (Minimum)	21
Shell Size (MIL)	G
Shielding	Shielded
Termination	Crimp
Voltage Rating	500 V

D38999/26FG Series

...

Part	Contact Shape	Operating Temperature (Max)	Operating Temperature (Min)	Note	Shell Size (MIL)	Housing Color	Mounting Type	Ingress Protection	Type	Shell Finish	Qualification	Grade	Fastening Type	Contact Type	Contact Size	Features	Shell Material	Number of Positions	Shielding	Connector Type	Orientation	Shell Size - Insert Width	Shell Size - Insert Length	Current Rating	Termination	Color	Primary Material	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Material Flammability Rating	Contact Finish - Mating	Insert Material	Applications	Contact Material	Contact Finish Thickness - Mating	Ingress Protection Description	Ingress Protection IP Rating	Contact Size Options
Amphenol Aerospace Operations D38999/26FG11PB-LC	Circular	200 °C	-65 °C	Contacts Not Included	G	Silver	Free Hanging (In-Line)	Environment Resistant	For Male Pins	Electroless Nickel	MIL-DTL-38999 Series III	Military	Threaded	Crimp	12	Coupling Nut Self Locking	Aluminum	11	Shielded	Plug Housing	B	11 mm	21 mm
Amphenol Aerospace Operations D38999/26FG41PN		125 °C	-65 °C		G		Free Hanging (In-Line)	Waterproof		Electroless Nickel	MIL-DTL-38999 Series III	Military	Threaded			Self Locking	Aluminum	41	Shielded	Male Pins Plug	N (Normal)			7.5 A	Crimp	Silver	Metal	21	41	UL94 V-0	Gold
Amphenol Aerospace Operations D38999/26FG39SBL	Circular	200 °C	-65 °C	Contacts Not Included	G	Silver	Free Hanging (In-Line)	Environment Resistant	For Female Sockets	Nickel	MIL-DTL-38999 Series III	Military	Threaded	Crimp	16 20	Coupling Nut	Aluminum	39	Shielded	Plug Housing	B							21	39			Thermoplastic
Amphenol Aerospace Operations D38999/26FG11SC		200 °C	-65 °C		G		Free Hanging (In-Line)			Nickel	MIL-DTL-38999 Series III	Military	Threaded			Coupling Nut	Aluminum	11	Shielded	Female Sockets Plug	C	11 mm	21 mm	23 A	Crimp	Silver	Metal				Gold	Thermoplastic	Aviation Marine Military	Copper Alloy	50 µin	Dust Tight Waterproof	IP67
Amphenol Aerospace Operations D38999/26FG11SN		200 °C	-65 °C				Free Hanging (In-Line)	Environment Resistant		Electroless Nickel		Military	Threaded				Aluminum Alloy	11	Shielded	Female Sockets Plug	N (Normal)	11 mm	21 mm		Crimp		Metal				Gold
Amphenol Aerospace Operations D38999/26FG16AB	Circular	200 °C	-65 °C	Contacts Not Included	G	Silver	Free Hanging (In-Line)	Environment Resistant	For Male Pins	Electroless Nickel	MIL-DTL-38999 Series III	Military	Threaded	Crimp	16 S	Coupling Nut Self Locking	Aluminum	16	Shielded	Plug Housing	B	16 mm	21 mm
Amphenol Aerospace Operations D38999/26FG11SA		200 °C	-65 °C		G		Free Hanging (In-Line)			Nickel			Threaded			Coupling Nut	Aluminum	11	Shielded	Female Sockets Plug	A	11 mm	21 mm	23 A	Crimp	Silver	Metal				Gold	Thermoplastic	Aviation Marine Military	Copper Alloy	50 µin	Dust Tight Waterproof	IP67
Amphenol Aerospace Operations D38999/26FG16PBL
Amphenol Aerospace Operations D38999/26FG35SBL	Circular	200 °C	-65 °C	Contacts Not Included	G	Silver	Free Hanging (In-Line)	Environment Resistant	For Female Sockets	Nickel	MIL-DTL-38999 Series III	Military	Threaded	Crimp		Coupling Nut	Aluminum	79	Shielded	Plug Housing	B							21	35			Thermoplastic						22D
Amphenol Aerospace Operations D38999/26FG41HA							Free Hanging (In-Line)						Threaded					41	Shielded	Male Pins Plug	A				Crimp			21	41		Gold
