2351963-2
ActiveTE Connectivity AMP Connectors
46POS,HYBRID,REC HSG ASSY,SLD,COD A
2351963-2
ActiveTE Connectivity AMP Connectors
46POS,HYBRID,REC HSG ASSY,SLD,COD A
Description
General part information
2351963-2
46 Position Housing, Housing for Female Terminals, 3.8 mm / 6 mm [.15 in / .24 in] Centerline, Sealable, Black, Wire & Cable, Power & Signal
Technical Specifications
Parameters and characteristics for this part
| Specification | 2351963-2 |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Lever Lock |
| Features | Sealed |
| Insulation Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 46 |
| Number of Rows | 3 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.15 in |
| Row Spacing | 0.139 in |
