Description
General part information
12532
GEARMOTOR 30 RPM 12V
Technical Specifications
Parameters and characteristics for this part
| Specification | 12532 |
|---|---|
| Diameter - Shaft | 0.236 in |
| Function | Gearmotor |
| Gear Reduction Ratio | 100 |
| Length - Shaft and Bearing | 0.709 in |
| Mounting Hole Spacing | 1.22 in |
| RPM | 30 RPM |
| Size / Dimension Diameter | 1.457 in |
| Size / Dimension Shape | Round |
| Termination Style | Solder Tab |
| Type | DC Motor |
| Voltage - Rated | 12 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
