B25690A1128K103
ActiveEPCOS - TDK Electronics
CAP FILM 1200UF 10% 1.1KV RADIAL
B25690A1128K103
ActiveEPCOS - TDK Electronics
CAP FILM 1200UF 10% 1.1KV RADIAL
Description
General part information
B25690A1128K103
1200 µF Film Capacitor 1100V (1.1kV) Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | B25690A1128K103 |
|---|---|
| Applications | General Purpose |
| Capacitance | 1200 µF |
| ESR (Equivalent Series Resistance) | 1.2 mOhm |
| Height - Seated (Max) | 9.055 in |
| Lead Spacing | 1.969 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 4.567 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - DC | 1.1 kVDC |
