FWPQ2918BS-4R7M-RC
ActiveAllied Components International
47UH 20% FLAT WIRE SMD PWR IND
FWPQ2918BS-4R7M-RC
ActiveAllied Components International
47UH 20% FLAT WIRE SMD PWR IND
Description
General part information
FWPQ2918BS-4R7M-RC
4.7 µH Shielded Wirewound Inductor 28 A 2.86mOhm Max 2-SMD, Gull Wing
Technical Specifications
Parameters and characteristics for this part
| Specification | FWPQ2918BS-4R7M-RC |
|---|---|
| Current - Saturation (Isat) | 61.2 A |
| Current Rating | 28 A |
| DC Resistance (DCR) (Max) | 2.86 mOhm |
| Height - Seated (Max) | 0.701 in |
| Inductance | 4.7 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Gull Wing, 2-SMD |
| Package Name | SMD |
| Shielding | Shielded |
| Size / Dimension Length | 1.098 in |
| Size / Dimension Width | 1.098 in |
| Tolerance | 20 % |
| Type | Wirewound |
