3-1415419-5

Active

TE Connectivity AMP Connectors

RELAY GEN PURPOSE DPST 16A 220V

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

RELAY GEN PURPOSE DPST 16A 220V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY GEN PURPOSE DPST 16A 12V

Part	Relay Type	Contact Form	Coil Type	Load - Max Switching	Must Release Voltage	Must Operate Voltage	Contact Material	Termination Style	Coil Current	Coil Voltage	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Approval Agency	Coil Resistance	Contact Rating (Current)	Switching Voltage [Max]
TE Connectivity AMP Connectors 4-1415419-0	General Purpose	DPST-NO (2 Form A)	Non Latching	6400 VA	0.9 VDC	7.5 VDC	Silver Copper (AgCu3)	Connector	60 mA	12 VDC	85 °C	-20 C	Chassis Mount	cURus, VDE	200 Ohms	16 A	400 VAC
TE Connectivity AMP Connectors 3-1415419-5	General Purpose	DPST-NO (2 Form A)	Non Latching	6400 VA	16 VAC	187 VAC	Silver Copper (AgCu3)	Connector	54 mA	220 VAC/DC	85 °C	-20 C	Chassis Mount	cURus, VDE	4.05 kOhms	16 A	400 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay DPST-NO (2 Form A) 220VAC Coil Chassis Mount
