PKJ7217KWPI
ActiveFlex Power Modules
14-160 V12.4215.18 V200 W14.5 A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PKJ7217KWPI
ActiveFlex Power Modules
14-160 V12.4215.18 V200 W14.5 A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PKJ7217KWPI |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | UL, cURus |
| Control Features | Active Low, Enable |
| Current - Output (Max) [Max] | 14.5 A |
| Efficiency | 90 % |
| Features | Remote On/Off, Adjustable Output, Baseplate, Remote Sense |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 115 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Half Brick |
| Power (Watts) | 200 W |
| Size / Dimension [x] | 2.4 in |
| Size / Dimension [x] | 61 mm |
| Size / Dimension [y] | 2.28 in |
| Size / Dimension [y] | 57.9 mm |
| Size / Dimension [z] | 0.5 in |
| Size / Dimension [z] | 12.7 mm |
| Standard Number | 62368-1 |
| Supplier Device Package | Half Brick |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 160 V |
| Voltage - Input (Min) [Min] | 14 V |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 13.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 113.93 | |
| 5 | $ 113.03 | |||
| 10 | $ 112.12 | |||
| 36 | $ 104.89 | |||
| 72 | $ 101.27 | |||
Description
General part information
PKJ7217KWPI
Isolated Module DC DC Converter 1 Output 13.8V 14.5A 14V - 160V Input
