CO75D6-125.000-33JDTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 125.0000MHZ LVDS SMD
CO75D6-125.000-33JDTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 125.0000MHZ LVDS SMD
Description
General part information
CO75D6-125.000-33JDTSTK
125 MHz XO (Standard) LVDS Oscillator 3.3V Enable/Disable 6-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | CO75D6-125.000-33JDTSTK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 100 mA |
| Frequency | 125 MHz |
| Frequency Stability | 20 ppm, 30 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.063 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | LVDS |
| Package / Case | No Lead, 6-SMD |
| Size / Dimension Length | 0.276 in |
| Size / Dimension Width | 0.197 in |
| Type | XO (Standard) |
| Voltage - Supply | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
