653-500-1-1-2-36
ActiveNOSHOK, Inc.
PRESSURE TRANSMITTER, GAUGE, 0 TO 500PSI
653-500-1-1-2-36
ActiveNOSHOK, Inc.
PRESSURE TRANSMITTER, GAUGE, 0 TO 500PSI
Description
General part information
653-500-1-1-2-36
653-500-1-1-2-36 is a 653 series pressure transmitter & transducer. Ideal for applications including hydraulics & pneumatics, automotive, pumps & compressors, refrigeration controls and transportation.
Technical Specifications
Parameters and characteristics for this part
| Specification | 653-500-1-1-2-36 |
|---|---|
| Accuracy | 0.5 % RH |
| Applications | Industrial Automation |
| Features | Temperature Compensated |
| Maximum Pressure | 1000 PSI |
| Operating Pressure | 500 PSI |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -30 °C |
| Output Current (Max) | 20 mA |
| Output Current (Min) | 4 mA |
| Output Type | Analog Current |
| Package / Case | Threaded, Cylinder |
| Port Diameter | 0.25 " |
| Port Feature | NPT |
| Port Gender | Male |
| Port Style | Threaded |
| Pressure Type | Gauge |
| Termination Style | Flying Lead |
| Voltage - Supply (Maximum) | 36 VDC |
| Voltage - Supply (Minimum) | 12 VDC |
