PDU3XVSRHWA
ObsoleteEaton Tripp Lite
PDU INTL 3-PHASE SWITCHED
PDU3XVSRHWA
ObsoleteEaton Tripp Lite
PDU INTL 3-PHASE SWITCHED
Description
General part information
PDU3XVSRHWA
PDU INTL 3-PHASE SWITCHED
Technical Specifications
Parameters and characteristics for this part
| Specification | PDU3XVSRHWA |
|---|---|
| AC Outlets (Count) | 24 count |
| Approval Agency | FCC, CSA, UL, NOM, CE |
| Connector - AC Input | Hardwired |
| Connector - AC Output | C19, IEC 320-C13 |
| Connector - AC Output Quantity (C19) | 12 pcs |
| Connector - AC Output Quantity (IEC 320-C13) | 12 pcs |
| Current - Max | 40 A |
| Features | Programmable Alerts, Load Meter, Ethernet Control and Monitor Interface for Individual Outlets |
| Housing Material | Metal |
| Mounting Type | Rack, Vertical |
| Overload Protection | Circuit Breaker(s) |
| Region Utilized | North America |
| Type | PDU (Power Distribution Unit) |
| Voltage - Input | 400 VDC |
| Weight | 13 lbs |
