70743SCS
ActiveCentury Spring Corp
COMP O= .240,L= .44,W= .042
70743SCS
ActiveCentury Spring Corp
COMP O= .240,L= .44,W= .042
Description
General part information
70743SCS
COMP O= .240,L= .44,W= .042
Technical Specifications
Parameters and characteristics for this part
| Specification | 70743SCS |
|---|---|
| Diameter - Inside | 0.156 in |
| Diameter - Outside | 0.24 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 0.44 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 105 lbs/in |
| Type | Compression |
| Wire Diameter | 0.042 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
