65-02-GEL60HF-0180
ObsoleteParker Chomerics
THERM-A-GAP GEL 60HF 6.2 W/M-K D
65-02-GEL60HF-0180
ObsoleteParker Chomerics
THERM-A-GAP GEL 60HF 6.2 W/M-K D
Description
General part information
65-02-GEL60HF-0180
Thermal Silicone Gel 180cc Cartridge
Technical Specifications
Parameters and characteristics for this part
| Specification | 65-02-GEL60HF-0180 |
|---|---|
| Color | Gray, Black |
| Features | Low Outgassing (ASTM E595) |
| Material Flammability Rating | UL94 V-0 |
| Shelf Life | 12 Months |
| Shelf Life Start | Date of Manufacture |
| Size / Dimension | Cartridge |
| Size / Dimension Shape | Cartridge |
| Size / Dimension Volume | 180 cc |
| Size / Dimension Weight | 180 cc |
| Storage/Refrigeration Temperature (Maximum) | 90 °F |
| Storage/Refrigeration Temperature (Minimum) | 50 °F |
| Thermal Conductivity | 6.2 W/m-K |
| Type | Silicone Gel |
| Usable Temperature Range (Max) | 392 °F |
| Usable Temperature Range (Min) | -67 °F |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
