CML155M50
ActiveNTE Electronics, Inc
CAP CER 1.5UF 50V Z5U RADIAL
CML155M50
ActiveNTE Electronics, Inc
CAP CER 1.5UF 50V Z5U RADIAL
Description
General part information
CML155M50
1.5 µF ±20% 50V Ceramic Capacitor Z5U Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | CML155M50 |
|---|---|
| Applications | Bypass, Decoupling |
| Capacitance | 1.5 µF |
| Height - Seated (Max) | 0.36 in |
| Lead Spacing | 0.2 in |
| Lead Style | Straight |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | 10 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.3 in |
| Size / Dimension Width | 0.15 in |
| Temperature Coefficient | Z5U |
| Tolerance | 20 % |
| Voltage - Rated | 50 V |
