Specification	2-2327042-3

Color	Black
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Male Pin
Fastening Type	Latch Holder
Features	Sealed, Terminal Position Lock (TPA)
Insulation Material	Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type	Free Hanging (In-Line)
Number of Positions	2
Number of Rows	1
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Pitch	0.197 in

Superseal Pro Series

...

Part	Connector Type	Number of Positions	Number of Rows	Fastening Type	Color	Contact Type	Mounting Type	Pitch	Features	Operating Temperature (Max)	Operating Temperature (Min)	Contact Termination	Insulation Material	Accessory Type
TE Connectivity AMP Connectors 2356631-2	Receptacle	4	2	Latch Holder	Black	Tab	Free Hanging (In-Line)	0.197 in	Sealed	125 °C	-40 °C	Crimp	Glass Filled Polybutylene Terephthalate (PBT)
TE Connectivity AMP Connectors 2375555-3	Housing for Female Insert	8	2	Latch Lock	Black	Female Socket	Free Hanging (In-Line)	0.185 in	Sealed	125 °C	-40 °C	Crimp	Glass Filled Polybutylene Terephthalate (PBT)
TE Connectivity AMP Connectors 2050052-3	Receptacle	4	1	Latch Lock	Black	Female Socket	Free Hanging (In-Line)	0.197 in	Sealed	120 °C	-40 °C	Crimp
TE Connectivity AMP Connectors 2363791-2														Backshell
TE Connectivity AMP Connectors 1-2356631-4	Receptacle	3	2	Latch Holder	Black	Tab	Free Hanging (In-Line)	0.197 in		125 °C	-40 °C	Crimp	Glass Filled Polybutylene Terephthalate (PBT)
TE Connectivity AMP Connectors 1-2375555-2
TE Connectivity AMP Connectors 2356607-3	Plug	4	2	Latch Lock	Black	Female Socket	Free Hanging (In-Line)	0.197 in	Sealed	125 °C	-40 °C	Crimp
TE Connectivity AMP Connectors 1-2356607-2	Plug	3	2	Latch Lock	Black	Male Pin	Free Hanging (In-Line)	0.197 in		125 °C	-40 °C	Crimp	Glass Filled Polybutylene Terephthalate (PBT)
TE Connectivity AMP Connectors 3-2356631-2	Receptacle	3	2	Latch Holder	Black	Tab	Free Hanging (In-Line)	0.197 in		125 °C	-40 °C	Crimp	Glass Filled Polybutylene Terephthalate (PBT)
TE Connectivity AMP Connectors 2050049-1	Housing for Female Insert	3	1	Latch Holder	Black	Female Socket	Free Hanging (In-Line)	0.197 in	Terminal Position Lock (TPA)	120 °C	-40 °C	Crimp	Glass Filled Nylon Polyamide (PA)
