Specification	095-900-550-036

1st Connector	MCX Plug, Right Angle
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	MCX Plug, Right Angle
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	RG, 174
Color	Black
Frequency - Max	1 GHz
Length	36 in
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Overall Impedance	50 Ohms
Style	MMCX

095-900 Series

...

Part	Operating Temperature (Min)	Operating Temperature (Max)	Frequency - Max	Overall Impedance	Cable Impedance	1st Contact Gender	Cable Type	Color	2nd Connector	2nd Contact Gender	Length (ft)	1st Connector	1st Connector Mounting Type	Style	2nd Connector Mounting Type	Length
McGill Microwave Systems 095-900-547M200	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MCX Plug Right Angle	Male	6.6 ft	MCX Plug Right Angle	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)
McGill Microwave Systems 095-900-548-018	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MMCX Plug	Male		MMCX Plug	Free Hanging (In-Line)	MMCX	Free Hanging (In-Line)	18 in
McGill Microwave Systems 095-900-549-018	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MMCX Plug Right Angle	Male		MMCX Plug	Free Hanging (In-Line)	MMCX	Free Hanging (In-Line)	18 in
McGill Microwave Systems 095-900-547-036	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MCX Plug Right Angle	Male		MCX Plug Right Angle	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)	36 in
McGill Microwave Systems 095-900-549M075	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MMCX Plug Right Angle	Male		MMCX Plug	Free Hanging (In-Line)	MMCX	Free Hanging (In-Line)	29.53 in
McGill Microwave Systems 095-900-551-036	-40 °C	85 °C	12 Gbps	75 Ohms		Male	Belden 4855R	Black	MCX Plug Right Angle	Male		MCX Plug Right Angle	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)	36 in
McGill Microwave Systems 095-900-545-036	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MCX Plug	Male		MCX Plug	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)	36 in
McGill Microwave Systems 095-900-545-012	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MCX Plug	Male		MCX Plug	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)	12 in
McGill Microwave Systems 095-900-546-036	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MCX Plug Right Angle	Male		MCX Plug	Free Hanging (In-Line)	MCX	Free Hanging (In-Line)	36 in
McGill Microwave Systems 095-900-548M100	-40 °C	85 °C	1 GHz	50 Ohms	50 Ohms	Male	174 RG	Black	MMCX Plug	Male		MMCX Plug	Free Hanging (In-Line)	MMCX	Free Hanging (In-Line)	39.4 in
