VTX-214-001-105
ActiveVigortronix
AC/DC PCB MOUNT POWER SUPPLY, CLASS II, FIXED, 90 V, 265 V, 1 W, 5 V, 200 MA ROHS COMPLIANT: YES
VTX-214-001-105
ActiveVigortronix
AC/DC PCB MOUNT POWER SUPPLY, CLASS II, FIXED, 90 V, 265 V, 1 W, 5 V, 200 MA ROHS COMPLIANT: YES
Description
General part information
VTX-214-001-105
Enclosed AC DC Converters 1 Output 5.1V 200mA 90 ~ 265 VAC, 100 ~ 370 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-214-001-105 |
|---|---|
| Applications | ITE (Commercial), Household Appliances |
| Approval Agency | CE, EN |
| Current - Output (Max) | 200 mA |
| Efficiency | 60 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 1 W |
| Size / Dimension Height | 0.75 in |
| Size / Dimension Length | 0.94 in |
| Size / Dimension Width | 0.91 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 265 VAC |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Input (DC) Maximum | 370 V |
| Voltage - Input (DC) Minimum | 100 V |
| Voltage - Output 1 | 5.1 V |
| Weight | 0.044 lb |
