CFM-A225C-220-350-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 120X25.4MM 24VDC WIRE
CFM-A225C-220-350-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 120X25.4MM 24VDC WIRE
Description
General part information
CFM-A225C-220-350-20
Fan Tubeaxial 24VDC Square - 120mm L x 120mm H omniCOOL™ Magnetic Sleeve 69.7 CFM (1.95mł/min) 3 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-A225C-220-350-20 |
|---|---|
| Air Flow | 69.7 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | omniCOOL™ Magnetic Sleeve |
| Current Rating | 0.17 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime | 40000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 37.8 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 4.08 W |
| RPM | 2000 RPM |
| Size / Dimension Height | 120 mm |
| Size / Dimension Length | 120 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.1 in H2O |
| Termination | 3 Wire Leads |
| Termination Leads Count | 3 |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 26.4 VDC |
| Voltage Range (Min) | 21.6 VDC |
| Width | 1 in |
