PS8551AL4-AX
ActiveCEL
IC OPAMP ISOLATION 1 CIRC 8DIPGW
Deep-Dive with AI
Search across all available documentation for this part.
PS8551AL4-AX
ActiveCEL
IC OPAMP ISOLATION 1 CIRC 8DIPGW
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PS8551AL4-AX |
|---|---|
| -3db Bandwidth | 100 kHz |
| Amplifier Type | Isolation |
| Current - Input Bias | 1 µA |
| Current - Output / Channel | 7.8 mA |
| Current - Supply | 13.5 mA |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Supplier Device Package | 8-DIP Gull Wing |
| Voltage - Input Offset | 2 mV |
| Voltage - Supply Span (Max) [Max] | 5.5 V |
| Voltage - Supply Span (Min) [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 50 | $ 10.02 | |
Description
General part information
PS8551AL4-AX
Isolation Amplifier 1 Circuit 8-DIP Gull Wing
Documents
Technical documentation and resources
No documents available
