Description
General part information
PRT-15898
2 Position Wire to Board Terminal Block Horizontal with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | PRT-15898 |
|---|---|
| Color | Green |
| Contact Material | Brass |
| Current | 11 A |
| Features | Lever Actuated |
| Housing Material | PBT, Polybutylene Terephthalate |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.197 in |
| Plating | Tin Plated |
| Positions Per Level | 2 |
| Voltage | 250 V |
| Wire Gauge (AWG) (Max) | 22 AWG |
| Wire Gauge (AWG) (Min) | 18 AWG |
| Wire Termination | Leg Spring, Screwless, Push-In Spring |
