14-131.022
ActiveEAO
SWITCH PB DPST-NO/NC 5A 250V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
14-131.022
ActiveEAO
SWITCH PB DPST-NO/NC 5A 250V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 14-131.022 |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Round, Button (Not Included) |
| Circuit | DPST-NO/NC |
| Current Rating (Amps) | 5 A |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Mechanical Life | 2000000 Cycles |
| Mounting Type | Panel Mount, Front |
| Operating Temperature [Max] | 55 °C |
| Operating Temperature [Min] | -25 °C |
| Panel Cutout Dimensions [diameter] | 22.3 mm |
| Switch Function | Off-Mom, On-Mom |
| Termination Style | 0.11 in |
| Termination Style | Quick Connect, Solder |
| Termination Style | 2.8 mm |
| Type | Standard |
| Voltage Rating - AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 36.90 | |
| 10 | $ 33.58 | |||
| 25 | $ 32.01 | |||
| 50 | $ 29.87 | |||
| 100 | $ 28.70 | |||
| 250 | $ 26.74 | |||
14-131 Series
SWITCH PB DPST-NO/NC 5A 250V
| Part | Circuit | Actuator Marking | Mounting Type | Voltage Rating - AC | Switch Function | Current Rating (Amps) | Termination Style | Termination Style | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Actuator Type | Type | Panel Cutout Dimensions [diameter] | Mechanical Life | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
EAO 14-131.022 | DPST-NO/NC | No Marking | Panel Mount, Front | 250 V | Off-Mom, On-Mom | 5 A | 0.11 in | Quick Connect, Solder | 2.8 mm | 55 °C | -25 °C | Round, Button (Not Included) | Standard | 22.3 mm | 2000000 Cycles | IP67 - Dust Tight, Waterproof |
Description
General part information
14-131 Series
Pushbutton Switch DPST-NO/NC Standard Panel Mount, Front
