CI0103P1VK0-NH

Active

Cvilux USA

3 POS 2.00MM(.079) SINGLE ROW ST

Search across all available documentation for this part.

Active

Cvilux USA

3 POS 2.00MM(.079) SINGLE ROW ST

Technical Specifications

Parameters and characteristics for this part

Specification	CI0103P1VK0-NH

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	120 µin
Contact Finish Thickness - Mating	3.05 Ám
Contact Finish Thickness - Post	120 Áin
Contact Finish Thickness - Post	3.05 Ám
Contact Length - Post [x]	0.134 in
Contact Length - Post [x]	3.4 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	2 A
Fastening Type	Detent Lock
Insulation Color	Natural
Insulation Height	0.24 in
Insulation Height	6.1 mm
Insulation Material	Polyamide (PA6T), Halogen Free, Nylon 6T
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-25 °C
Pitch - Mating [x]	0.079 in
Pitch - Mating [x]	2 mm
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Kinked Pin, Solder
Voltage Rating	250 VAC

3 POS 2.00MM(.079) SINGLE ROW ST

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Post	Contact Type	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height	Insulation Height	Number of Positions Loaded	Current Rating (Amps)	Insulation Material	Voltage Rating	Contact Shape	Mounting Type	Number of Rows	Insulation Color	Material Flammability Rating	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Contact Material	Termination	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Style	Pitch - Mating [x]	Pitch - Mating [x]	Shrouding
Cvilux USA CI0103P1VK0-NH	120 Áin	3.05 Ám	Tin	Male Pin	Detent Lock	-25 °C	105 ░C	0.24 in	6.1 mm	All	2 A	Halogen Free, Nylon 6T, Polyamide (PA6T)	250 VAC	Square	Through Hole	1	Natural	UL94 V-0	0.134 in	3.4 mm	Header	Brass	Kinked Pin, Solder	120 µin	3.05 Ám	Board to Cable/Wire	0.079 in	2 mm	Shrouded - 4 Wall
