9007MS02G0100
ActiveSCHNEIDER ELECTRIC
LIMIT SWITCH, IP67, ROLLER PLUNGER, SPDT, 100 MA, 125 V, 80 OZF, 9007 SERIES
9007MS02G0100
ActiveSCHNEIDER ELECTRIC
LIMIT SWITCH, IP67, ROLLER PLUNGER, SPDT, 100 MA, 125 V, 80 OZF, 9007 SERIES
Description
General part information
9007MS02G0100
Switch SPDT Chassis Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 9007MS02G0100 |
|---|---|
| Actuator Type | Roller Plunger |
| Circuit | SPDT |
| Current Rating | 100 mA, 30 mA |
| Electrical Life (Cycles) | 100000 Cycles |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mechanical Life (Cycles) | 10000000 Cycles |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 104 °C |
| Operating Temperature (Min) | -40 °C |
| Switch Function | On-Mom |
| Termination Style | Cable Leads |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 28 V |
