DGB9M
ActiveD SUB CONNECTOR ADAPTER, STANDARD D SUB, PLUG, 9 POSITIONS, STANDARD D SUB, PLUG, 9 POSITIONS
DGB9M
ActiveD SUB CONNECTOR ADAPTER, STANDARD D SUB, PLUG, 9 POSITIONS, STANDARD D SUB, PLUG, 9 POSITIONS
Description
General part information
DGB9M
The DGB9M is a slim-line gender changer DB9 Male to DB9 Male Adapter, dual-purpose slim-line gender changer allows mismatched D-sub connectors to mate and are Panel-mounted to pass cables through a bulkhead. The low profile design reduces leverage strain on overstressed computer ports and is fully shielded for electrically noisy environments. Universally designed for serial or parallel applications.
Technical Specifications
Parameters and characteristics for this part
| Specification | DGB9M |
|---|---|
| Connector Style | Gender Changer |
| Contact Finish | Gold |
| Contact Finish Thickness | 0 |
| Contact Finish Thickness | Flash |
| Contact Finish Thickness (string set options) | Flash |
| Convert From (Adapter End) Pin Count | 9 |
| Convert From (Adapter End) Pin Gender | Male |
| Convert From (Adapter End) Type | D-Sub |
| Convert To (Adapter End) | Pin Male, D-Sub |
| Convert To (Adapter End) Pin Count | 9 pins |
| Current Rating | 3 A |
| Features | Grounding Indents |
| Finish | Tin-Nickel Plated |
| Housing Color | Blue |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Rows | 2 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Shell Material | Steel |
| Shielding | Shielded |
