PIN HEADER, SINGLE ROW, 18 PIN,

Search across all available documentation for this part.

Active

Oupiin

PIN HEADER, SINGLE ROW, 18 PIN,

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	2012-1X18G00S/083/045R/I24	2012 Series

Color	-	Black
Contact Finish - Post (Mating)	Gold	Gold
Contact Finish Thickness - Post (Mating)	Flash	Flash
Length - Overall Pin	-	21.1 mm
Length - Overall Pin	-	0.831 in
Length - Post (Mating) [x]	4.5 mm	4.5 - 5.6 mm
Length - Post (Mating) [x]	0.177 in	0.177 - 0.22 in
Length - Stack Height	-	0.5 in
Length - Stack Height	-	12.7 mm
Length - Tail	-	2.8 mm
Length - Tail	-	0.11 in
Length - Tail [x]	0.327 in	0.327 in
Length - Tail [x]	8.3 mm	8.3 mm
Mounting Type	Through Hole	Through Hole
Number of Positions	18	2 - 18
Number of Rows	1	1
Pitch	-	2.54 mm
Pitch	-	0.1 in
Termination	Solder	Solder

PIN HEADER, SINGLE ROW, 2 PIN, S

Part	Termination	Number of Positions	Length - Tail	Length - Tail	Mounting Type	Color	Length - Stack Height [x]	Length - Stack Height [x]	Number of Rows	Length - Overall Pin	Length - Overall Pin	Contact Finish Thickness - Post (Mating)	Pitch [x]	Pitch [x]	Contact Finish - Post (Mating)	Length - Post (Mating) [x]	Length - Post (Mating) [x]	Length - Tail [x]	Length - Tail [x]
Oupiin 2012-1X02G00S-2.8-5.6-21.1B-HT	Solder	2	2.8 mm	0.11 in	Through Hole	Black	0.5 in	12.7 mm	1	21.1 mm	0.831 in	Flash	2.54 mm	0.1 in	Gold	5.6 mm	0.22 in
Oupiin 2012-1X18G00S/083/045R/I24	Solder	18			Through Hole				1			Flash			Gold	4.5 mm	0.177 in	0.327 in	8.3 mm
