Description
General part information
MC68030RC50C
68030 Microprocessor IC M680x0 1 Core, 32-Bit 50MHz 128-PGA (34.55x34.55)
Technical Specifications
Parameters and characteristics for this part
| Specification | MC68030RC50C |
|---|---|
| Additional Interfaces | SPI, SCI |
| Bus Width | 32 Bit |
| Core Processor | 68030 |
| Graphics Acceleration | No |
| Mounting Type | Through Hole |
| Number of Cores | 1 Core |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Package / Case | 128-BPGA |
| Package Length | 34.55 mm |
| Package Name | 128-PGA |
| Package Width | 34.55 mm |
| Speed | 50 MHz |
| Voltage - I/O | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
