1808242
7 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.098" (2.50mm) 90°, Right Angle Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 1808242 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Current - IEC | 6 A |
| Current - UL | 5 A |
| Features | Solder Retention |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Liquid Crystal Polymer, LCP |
| Insulation Height | 0.197 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Surface Mount |
| Number of Levels | 1 |
| Number of Positions | 7 |
| Pitch | 0.098 in |
| Positions Per Level | 7 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
| Voltage - UL | 150 V |
