VTX-146-625-140
ActiveVigortronix
PWR XFMR TOROIDAL 625VA CHAS MT
VTX-146-625-140
ActiveVigortronix
PWR XFMR TOROIDAL 625VA CHAS MT
Description
General part information
VTX-146-625-140
PWR XFMR TOROIDAL 625VA CHAS MT
Technical Specifications
Parameters and characteristics for this part
| Specification | VTX-146-625-140 |
|---|---|
| Center Tap | No |
| Current - Output (Max) | 7.8 A |
| Height - Seated (Max) | 72 mm |
| Mounting Type | Chassis Mount |
| Power - Max | 625 W |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Dual |
| Size / Dimension Diameter | 144 mm |
| Termination Style | Wire Leads |
| Type | Toroidal |
| Voltage - Isolation | 4200 VDC |
| Voltage - Primary | 230 V |
| Voltage - Secondary (Full Load) (Parallel) | 40 V |
| Voltage - Secondary (Full Load) (Series) | 80 V |
| Weight | 11.5 lbs |
