MSCC-0300
ActiveAstrodyne TDI
AC/DC CONVERTER 3.3V 25W
MSCC-0300
ActiveAstrodyne TDI
AC/DC CONVERTER 3.3V 25W
Description
General part information
MSCC-0300
Enclosed AC DC Converters 1 Output 3.3V 90 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | MSCC-0300 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | cURus, CE |
| Current - Output 1 | 7.5 A |
| Efficiency | 70 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 25 W |
| Size / Dimension Height | 1 in |
| Size / Dimension Length | 4.76 in |
| Size / Dimension Width | 2.56 in |
| Standard Number | 60601-1, 60950-1 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 3.3 V |
