PCHC420R8-R22M-RC
ActiveAllied Components International
.22UH +/-20% SMD MOLDED PWRCHOKE
PCHC420R8-R22M-RC
ActiveAllied Components International
.22UH +/-20% SMD MOLDED PWRCHOKE
Description
General part information
PCHC420R8-R22M-RC
220 nH Shielded Inductor 9 A 6.6mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC420R8-R22M-RC |
|---|---|
| Current - Saturation (Isat) | 12.5 A |
| Current Rating | 9 A |
| DC Resistance (DCR) (Max) | 6.6 mOhm |
| Height - Seated (Max) | 0.079 in |
| Inductance | 220 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.181 in |
| Size / Dimension Width | 0.161 in |
| Tolerance | 20 % |
