CY23FS04ZXCT
ObsoleteInfineon Technologies
IC FANOUT DIST 16TSSOP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CY23FS04ZXCT
ObsoleteInfineon Technologies
IC FANOUT DIST 16TSSOP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CY23FS04ZXCT |
|---|---|
| Differential - Input:Output | False |
| Divider/Multiplier | False |
| Frequency - Max [Max] | 166.7 MHz |
| Input | LVTTL, Crystal, LVCMOS |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Output | LVCMOS |
| Package / Case | 16-TSSOP |
| Package / Case [x] | 0.173 in |
| Package / Case [y] | 4.4 mm |
| PLL | Yes with Bypass |
| Ratio - Input:Output | 3:4 |
| Supplier Device Package | 16-TSSOP |
| Type | Multiplexer, Fanout Distribution, Zero Delay Buffer |
| Voltage - Supply | 2.5 V, 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 21 | $ 14.61 | |
| 21 | $ 14.61 | |||
Description
General part information
CY23FS04 Series
Fanout Distribution, Multiplexer, Zero Delay Buffer IC 166.7MHz 1 16-TSSOP (0.173", 4.40mm Width)
