AM6055
ActiveAtlanta Micro Inc.
SP8T RF SWITCH, 18GHZ, ABSORPTIV
AM6055
ActiveAtlanta Micro Inc.
SP8T RF SWITCH, 18GHZ, ABSORPTIV
Description
General part information
AM6055
SP8T RF SWITCH, 18GHZ, ABSORPTIV
Technical Specifications
Parameters and characteristics for this part
| Specification | AM6055 |
|---|---|
| Circuit | SP8T |
| Frequency Range (Max) | 18 GHz |
| Frequency Range (Min) | 10 MHz |
| Impedance | 50 Ohm |
| Insertion Loss | 2.5 dB |
| Isolation | 50 dB |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Length | 5 mm |
| Package Name | 32-QFN |
| Package Width | 5 mm |
| Test Frequency | 6 GHz |
| Topology | Absorptive |
| Voltage - Supply (Maximum) | 5 V |
| Voltage - Supply (Minimum) | 3.3 V |
