CAF-A225B-118-300
ActiveSame Sky (Formerly CUI Devices)
AC FAN, 120 X 120 X 25 MM, 110 ~
CAF-A225B-118-300
ActiveSame Sky (Formerly CUI Devices)
AC FAN, 120 X 120 X 25 MM, 110 ~
Description
General part information
CAF-A225B-118-300
Fan Tubeaxial 110VAC Square - 120mm L x 120mm H Ball 45.5 CFM (1.27mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CAF-A225B-118-300 |
|---|---|
| Air Flow | 45.5 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 150 mA |
| Fan Type | Tubeaxial |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Aluminum |
| Noise | 35.2 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 10.8 W |
| RPM | 1700 RPM |
| Size / Dimension Height | 120 mm |
| Size / Dimension Length | 120 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.08 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 110 VAC |
| Width | 25.8 mm |
