IFDC5050HZER561M
ActiveVishay Dale
FIXED IND 560UH 1.1A 1070 OHM SM
IFDC5050HZER561M
ActiveVishay Dale
FIXED IND 560UH 1.1A 1070 OHM SM
Description
General part information
IFDC5050HZER561M
560 µH Shielded Wirewound Inductor 1.1 A 1.07Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | IFDC5050HZER561M |
|---|---|
| Current - Saturation (Isat) | 0.73 mA |
| Current Rating | 1.1 A |
| DC Resistance (DCR) (Max) | 1.07 Ohm |
| Frequency - Self Resonant | 2 MHz |
| Height - Seated (Max) | 0.315 in |
| Inductance | 560 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.484 in |
| Size / Dimension Width | 0.484 in |
| Tolerance | 20 % |
| Type | Wirewound |
