BJL36045
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
BJL36045
ActiveSCHNEIDER ELECTRIC
MOLDED CASE CIRCUIT BREAKER 600V
Description
General part information
BJL36045
Circuit Breaker Thermal Magnetic 45A 120 V AC 250 V DC Toggle DIN Rail
Technical Specifications
Parameters and characteristics for this part
| Specification | BJL36045 |
|---|---|
| Actuator Type | Toggle |
| Approval Agency | EN 60947-5-1, IEC 60947-5-1, UL489, IEC 60947-2, EN 60947-2, CSA C22.2 No 5, GB 14048.2 |
| Breaker Type | Thermal Magnetic |
| Current Rating | 45 A |
| Illumination | None |
| Mounting Type | DIN Rail |
| Number of Poles | 3 |
| Voltage Rating - AC | 120 V |
| Voltage Rating - DC | 250 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
