MAL250035472E3
ActiveVishay Dale
CAP ALUM 4700UF 20% 350V SCREW
MAL250035472E3
ActiveVishay Dale
CAP ALUM 4700UF 20% 350V SCREW
Description
General part information
MAL250035472E3
4700 µF 350 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 25mOhm @ 100Hz 5000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL250035472E3 |
|---|---|
| Applications | General Purpose |
| Capacitance | 4700 µF |
| ESR (Equivalent Series Resistance) | 25 mOhm |
| Height - Seated (Max) | 4.165 in |
| Impedance | 17 mOhms |
| Lead Spacing | 1.122 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Ripple Current | 17.4 A, 11.6 A |
| Size / Dimension Diameter | 2.559 in |
| Tolerance | 20 % |
| Voltage - Rated | 350 V |
