Specification	10091836-M0J-20DLF

Color	Gray
Connector Style	High Speed
Connector Type	Male Blades, Header
Connector Usage	Backplane
Contact Finish	Gold
Contact Finish Thickness	15 µin
Differential Pairs (Typical)	24
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Columns	4
Number of Positions Loaded	All
Termination	Press-Fit

10091836 Series

...

Part	Material Flammability Rating	Connector Style	Termination	Connector Type	Color	Connector Usage	Number of Positions Loaded	Number of Columns	Mounting Type	Contact Finish Thickness	Differential Pairs (Typical)	Contact Finish
Amphenol ICC (FCI) 10091836-A0J-10DLF	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole	15 µin	24	Gold
Amphenol ICC (FCI) 10091836-A0J-40B	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-V0J-30DLF	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-H0J-70DLF	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-P0J-20B	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-P0J-20DLF	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole	15 µin	24	Gold
Amphenol ICC (FCI) 10091836-V0J-70B	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-00J-80B	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-T0J-30B	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
Amphenol ICC (FCI) 10091836-10J-80DLF	UL94 V-0	High Speed	Press-Fit	Header Male Blades	Gray	Backplane	All	4	Through Hole		24	Gold
