General part information
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Blue 23 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 10GX32 0061000 |
|---|---|
| Cable Type | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.295 in |
| Jacket (Insulation) Diameter [diameter] | 7.49 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Blue |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 8 |
| Ratings | UL Style CMR |
| Usage | Network |
| Voltage | 300 V |
| Wire Gauge | 23 AWG |
CAT6A 4PRB U/UTP CMR REEL
| Part | Jacket (Insulation) Material | Number of Conductors | Length | Length | Cable Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Voltage | Conductor Insulation | Conductor Strand | Conductor Material | Usage | Features | Ratings | Jacket Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 10GX32 0061000 | Poly-Vinyl Chloride (PVC), Riser | 8 | 1000 ft | 304.8 m | Multi-Pair, Cat6a | 0.295 in | 7.49 mm | 23 AWG | 300 V | Polyolefin (PO) | Solid | Copper, Bare | Network | Rip Cord | UL Style CMR | Blue |
