PKE3313PI
ActiveFlex Power Modules
DC DC CONVERTER 12V 30W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PKE3313PI
ActiveFlex Power Modules
DC DC CONVERTER 12V 30W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PKE3313PI |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, UL, IEC, TUV, CSA |
| Control Features | Active Low, Enable |
| Current - Output (Max) [Max] | 2.5 A |
| Efficiency | 92 % |
| Features | Remote On/Off, Adjustable Output |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 110 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Sixteenth Brick |
| Power (Watts) | 30 W |
| Size / Dimension [x] | 1 in |
| Size / Dimension [x] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [z] | 11.4 mm |
| Size / Dimension [z] | 0.45 " |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 9 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 40.92 | |
| 5 | $ 40.60 | |||
| 10 | $ 40.28 | |||
| 25 | $ 39.00 | |||
| 50 | $ 37.08 | |||
| 100 | $ 34.52 | |||
| 250 | $ 34.01 | |||
Description
General part information
PKE3313PI
Isolated Module DC DC Converter 1 Output 12V 2.5A 9V - 36V Input
