Description
General part information
AM1DM-2415SH60MZ
Isolated Module DC DC Converter 1 Output 15V 670mA 21.6V - 26.4V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1DM-2415SH60MZ |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, UKCA, cURus |
| Current - Output (Max) | 670 mA |
| Efficiency | 76 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 7-SIP Module |
| Package Name | 7-SIP |
| Power (Watts) | 1 W |
| Size / Dimension Height | 0.49 in |
| Size / Dimension Length | 0.77 in |
| Size / Dimension Width | 0.39 in |
| Standard Number | 60601-1, 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 26.4 V |
| Voltage - Input (Min) | 21.6 V |
| Voltage - Isolation | 6 kV |
| Voltage - Output 1 | 15 V |
