SY89323LMG-TR
ActiveTRANSLATOR, 4 INPUT, 2.5 NS, 3 V TO 3.6 V, 8 PINS, MLF-EP
Deep-Dive with AI
Search across all available documentation for this part.
SY89323LMG-TR
ActiveTRANSLATOR, 4 INPUT, 2.5 NS, 3 V TO 3.6 V, 8 PINS, MLF-EP
Deep-Dive with AI
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 5.48 | |
| 25 | $ 4.57 | |||
| 100 | $ 4.15 | |||
| Digi-Reel® | 1 | $ 5.48 | ||
| 25 | $ 4.57 | |||
| 100 | $ 4.15 | |||
| Tape & Reel (TR) | 1000 | $ 4.15 | ||
| Microchip Direct | T/R | 1 | $ 5.48 | |
| 25 | $ 4.57 | |||
| 100 | $ 4.15 | |||
| 1000 | $ 3.47 | |||
| 5000 | $ 3.19 | |||
| 10000 | $ 2.97 | |||
Description
General part information
SY89323 Series
The SY89323L is a dual differential LVPECL-to-LVTTL translator. Because LVPECL (Low Voltage Positive ECL) levels are used, only +3.3V and ground are required. The SY89323L is functionally equivalent to the SY100EPT23L, but in an ultra-small 8-pin MLF® package that features a 70% smaller footprint. The ultra-small package and the dual gate design of the SY89823L make it ideal for applications that require the translation of a clock and data signal in a minimal space. The inputs are compatible with 10k and 100k input levels and any standard differential LVPECL input referenced to a VCC of 3.3V.
