VX-705-1058-122M880000TR
ActiveMicrochip Technology
5.0X7.0MM SMD CMOS/PECL VCXO
Deep-Dive with AI
DocumentsVX-705 Data Sheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | VX-705-1058-122M880000TR | VX-705 Series |
|---|---|---|
| - | - | |
| Base Resonator | Crystal | Crystal |
| Frequency | 122.88 MHz | 122.88 MHz |
| Frequency Stability | 20 ppm | 20 ppm |
| Function | Amplitude Control | Amplitude Control |
| Height - Seated (Max) [Max] | 0.082 " | 0.082 " |
| Height - Seated (Max) [Max] | 2.09 mm | 2.09 mm |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 6-SMD, No Lead | 6-SMD, No Lead |
| Size / Dimension [x] | 7 mm | 7 mm |
| Size / Dimension [x] | 0.276 " | 0.276 " |
| Size / Dimension [y] | 5 mm | 5 mm |
| Size / Dimension [y] | 0.197 " | 0.197 " |
| Type | VCXO | VCXO |
| Voltage - Supply | 3.3 V | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Microchip Direct | T/R | 1 | $ 7.69 | |
| 25 | $ 6.40 | |||
| 100 | $ 5.82 | |||
| 1000 | $ 5.62 | |||
| 5000 | $ 5.57 | |||
VX-705 Series
5.0x7.0mm SMD CMOS/PECL VCXO
| Part | Type | Package / Case | Frequency Stability | Function | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Base Resonator | Frequency | Mounting Type | Voltage - Supply | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology VX-705-ECE-KXAN-101M992000 | ||||||||||||||
Microchip Technology VX-705-1058-122M880000TR | VCXO | 6-SMD, No Lead | 20 ppm | Amplitude Control | 7 mm | 5 mm | 0.276 " | 0.197 " | Crystal | 122.88 MHz | Surface Mount | 3.3 V | 0.082 " | 2.09 mm |
Microchip Technology VX-705-ECE-KEAN-120M000000 | ||||||||||||||
Microchip Technology VX-705-ECE-KEAN-120M000000 |
Description
General part information
VX-705 Series
The VX-705 is a Voltage Control Crystal Oscillator that operates at the fundamental frequency of the internal crystal. The crystal is a high-Q quartz device that enables the circuit to achieve low phase noise jitter performance over a wide operating temperature range.
