TA3FLBX

Active

Switchcraft Inc.

CONN PLUG FMALE MINI XLR 3P SLDR

Search across all available documentation for this part.

Active

Switchcraft Inc.

CONN PLUG FMALE MINI XLR 3P SLDR

Technical Specifications

Parameters and characteristics for this part

CONN PLUG FMALE MINI XLR 3P SLDR

Part	Cable Opening [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish - Mating	Mounting Type	Shell Finish	Fastening Type	Shielding	Shell Material	Orientation	Termination	Applications	Color	Primary Material	Backshell Material, Plating	Contact Material	Features	Insert Material	Voltage Rating	Shell Size - Insert	Connector Type	Current Rating (Amps)
Switchcraft Inc. TA3FLBX	0.115 in, 0.19 in, 2.92 mm, 4.83 mm	85 °C	-55 °C	Silver	Free Hanging (In-Line)	Chrome	Latch Lock	Shielded	Copper Alloy	Keyed	Solder	Audio	Black	Metal	Thermoplastic	Copper Alloy	Backshell, Cable Clamp	Thermoplastic	125 VAC	Mini XLR	Female Sockets, Plug	5 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 11.18

General part information

3 Position Circular Connector Plug, Female Sockets Solder

Technical documentation and resources

No documents available
