Description
General part information
A11WAC-P27MBC0-0000
27 Position Circular Connector Plug, Male Pins Solder Cup
Technical Specifications
Parameters and characteristics for this part
| Specification | A11WAC-P27MBC0-0000 |
|---|---|
| Color | Silver |
| Connector Type | Male Pins, Plug |
| Contact Finish - Mating | Gold |
| Current Rating | 1 A |
| Fastening Type | Detent Lock |
| Ingress Protection Description | Water Resistant, Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP69K, IP68 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 27 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -51 °C |
| Orientation | A |
| Primary Material | Metal |
| Shell Finish | Chrome |
| Shell Material | Brass |
| Shell Size - Insert | 1 |
| Shell Size - Insert | 1 |
| Shielding | Shielded |
| Termination | Solder Cup |
