Description
General part information
L18P005D15AHV
Current Sensor 5A 1 Channel Hall Effect, Open Loop Bidirectional Module
Technical Specifications
Parameters and characteristics for this part
| Specification | L18P005D15AHV |
|---|---|
| Current - Sensing | 5 A |
| Current - Supply (Max) | 18 mA |
| For Measuring | AC, DC |
| Linearity Tolerance | 1 % |
| Mounting Type | Through Hole |
| Number of Channels | 1 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -30 °C |
| Output | Voltage, Ratiometric |
| Package / Case | Module |
| Polarization | Bidirectional |
| Response Time | 5 µs |
| Sensor Type | Hall Effect, Open Loop |
| Voltage - Supply (Maximum) | 15 V |
| Voltage - Supply (Minimum) | -12 V |
