Part	Note	Insulation Material	Number of Positions	Pitch	Contact Type	Color	Number of Rows	Contact Termination	Mounting Type	Connector Type	Operating Temperature (Max)	Operating Temperature (Min)	Fastening Type	Insulation Height	Termination	Contact Finish - Mating	Contact Material	Contact Length - Mating	Style	Voltage Rating	Pitch - Mating	Overall Contact Length	Contact Finish Thickness - Mating	Material Flammability Rating	Number of Positions Loaded	Features	Shrouding	Insulation Color	Contact Length - Post	Row Spacing - Mating	Contact Shape	Mated Stacking Height	Contact Finish	Pin or Socket	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Wire Entry Location	Wire Gauge or Range - AWG (Min)	Wire Gauge or Range - AWG (Max)	Tool Type	Tool Method	Ratcheting	For Use With/Related Products	Contact Finish - Post
Hirose Electric Co Ltd DF1B-8S-2.5R	Contacts Not Included	Nylon Polyamide (PA)	8	0.098 in	Female Socket	White	1	Crimp IDC	Free Hanging (In-Line)	Receptacle	85 °C	-35 °C
Hirose Electric Co Ltd DF1B-2EP-2.5RC	Contacts Not Included	Nylon Polyamide (PA)	2	0.098 in	Male Pin	White	1	Crimp IDC	Free Hanging (In-Line)	Plug	85 °C	-35 °C	Latch Lock
Hirose Electric Co Ltd DF1B-12DP-2.5DSA(01)		Nylon Polyamide (PA)	12		Male Pin		2		Through Hole	Header	85 °C	-35 °C	Push-Pull	0.374 in	Solder	Gold	Brass	0.177 in	Board Cable/Wire	250 V	0.098 in	0.417 in	8 µin	UL94 V-0	All	Keying Slot	Shrouded - 4 Wall	White	0.142 in	0.098 in	Square	14 mm
Hirose Electric Co Ltd DF1B-13EP-2.5RC	Contacts Not Included	Nylon Polyamide (PA)	13	0.098 in	Male Pin	White	1	Crimp IDC	Free Hanging (In-Line)	Plug	85 °C	-35 °C	Latch Lock
Hirose Electric Co Ltd DF1B-15P-2.5DSA		Nylon Polyamide (PA)	15		Male Pin		1		Through Hole	Header	85 °C	-35 °C	Push-Pull	0.374 in	Solder	Tin	Brass	0.177 in	Board Cable/Wire	250 V	0.098 in	0.417 in		UL94 V-0	All	Keying Slot	Shrouded - 4 Wall	White	0.142 in		Square	14 mm
Hirose Electric Co Ltd DF1B-2022SC								Crimp																									Tin	Socket	19.5 AWG	22 AWG
Hirose Electric Co Ltd DF1B-TA2428SHC																																					Side Entry	24 AWG	28 AWG	Hand Crimper	Manual	No Ratchet	Rectangular Contacts
Hirose Electric Co Ltd DF1B-34DP-2.5DSA		Nylon Polyamide (PA)	34		Male Pin		2		Through Hole	Header	85 °C	-35 °C	Push-Pull	0.374 in	Solder	Tin	Brass	0.177 in	Board Cable/Wire	250 V	0.098 in	0.417 in		UL94 V-0	All	Keying Slot	Shrouded - 4 Wall	White	0.142 in	0.098 in	Square	14 mm												Tin
Hirose Electric Co Ltd DF1B-13ES-2.5RC	Contacts Not Included	Nylon Polyamide (PA)	13	0.098 in	Female Socket	White	1	Crimp IDC	Panel Mount Snap-In	Receptacle	85 °C	-35 °C	Locking Ramp
Hirose Electric Co Ltd DF1B-3EP-2.5RC	Contacts Not Included	Nylon Polyamide (PA)	3	0.098 in	Male Pin	White	1	Crimp IDC	Free Hanging (In-Line)	Plug	85 °C	-35 °C	Latch Lock
