Specification	MAL212515332E3

Applications	General Purpose
Capacitance	3300 µF
ESR (Equivalent Series Resistance)	88 mOhm
Impedance	140 mOhms
Lifetime	10000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Axial
Polarization	Polar
Ripple Current	1.01 A, 1.313 A
Size / Dimension Diameter	0.591 in
Size / Dimension Length	1.181 in
Tolerance	20 %
Voltage - Rated	16 V
