Specification	225CKE450MJM

Applications	Bypass, Decoupling
Capacitance	2.2 µF
ESR (Equivalent Series Resistance)	150.71 Ohm
Height - Seated (Max)	0.512 in
Lead Spacing	0.138 in
Lifetime	2000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-25 °C
Package / Case	Can, Radial
Polarization	Polar
Ripple Current	30 mA, 75 mA
Size / Dimension Diameter	0.315 in
Tolerance	20 %
Voltage - Rated	450 V
